TYRE PROTECTION CHAINS FOR WHEEL LOADERS

Tyre Protection Chains are manufactured from a special mesh of high wear resistant but flexible Chrome, Manganese and Molybdenum alloy steel links. The mesh protects both the side walls and the tread of the expensive tyres from wear and tear. On the other hand, Tyre Protection Chains are flexible enough to take the shape of the tyre to ensure flawless operation. In addition, this flexibility prevents potential clogging of the chains that could affect the handling of the loader.

SAVE YOUR TYRES!
Wheel loader and other earth moving machine tyres are vulnerable and expensive and they increase the operational costs. By applying this simple protection, you cannot only reduce costs, but ensure higher productivity with additional benefits.

TESTED QUALITY
We keep quality under constant control and perform regular tensile, rupture and elongation tests in metal testing laboratories. The surface hardness and core hardness are checked with Micro Vickers and HRC hardness testers. The steel for the protection chains is manufactured in the EU and is hardened by forging with 600, 800 and 1000 tonne Hydraulic Pneumatic Hammers, with 5 hits per link.

TECHNICAL SUPPORT
Our trained technicians provide on-site installation and training for future maintenance along with spare parts, special tools and accessories, which are essential for delivering best performance and ensuring long service life of the product.

THE RIGHT CHOICE FOR YOUR NEEDS
YUDIN EQUIPMENT is ready to advise on what would be the best products for your specific applications. Get in contact with us today to discuss your needs.

TYRE PROTECTION CHAIN TYPES AND SIZES

X12 UNIVERSAL

Application Areas: Scrapyard, Recycling, Underground Mining, Construction, Tunnel.

Pod Dimensions (W x H x B): 29x39x61mm.

Engine Power: 42 kW - 125 kW.

Operating Weight: 3 - 20 Tones.

Tyre Size: 7.50 × 15 - 10 × 16.5 - 12 × 16.5 - 17.5 × 25 - 20.5 × 25 - 23.5 × 25.

TYRE PROTECTION CHAIN TYPES AND SIZES

X14 UNIVERSAL

Application Areas: Underground Mining, Hot Slag, Scrapyard, Recycling.

Pod Dimensions (W x H x B): 36x44x76 mm.

Engine Power: 42kW - 125 Kw.

Operating Weight: 3 - 20 tons.

Tyre Size: 7.50 × 15 - 10 × 16.5 - 12 × 16.5 - 17.5 × 25 - 20.5 × 25 - 23.5 × 25 - 16.00 × 25.

TYRE PROTECTION CHAIN TYPES AND SIZES

X16 UNIVERSAL

Application Areas: Scrapyard, Recycling, Underground Mining, Hot Slag, Open Pit Metal Mining.

Pod Dimensions (W x H x B): 42x56x83 mm.

Engine Power: 115kW - 274 kW.

Operating Weight: 15 - 40 tons.

Tyre Size: 16.00 × 25 - 18.00 × 25 - 23.5 × 25 - 26.5 × 25.

TYRE PROTECTION CHAIN TYPES AND SIZES

X18 UNIVERSAL

Application Areas: Granite Quarry, Open Pit Metal Mining, Hot Slag, Scrapyard, Recycling.

Pod Dimensions (W x H x B): 46x66x93 mm.

Engine Power: 199 kW - 403 kW.

Operating Weight: 25 - 82 tons.

Tyre Size: 23.5 × 25 - 26.5 × 25 - 29.5 × 25 - 35 / 65-33.

TYRE PROTECTION CHAIN TYPES AND SIZES

X22 UNIVERSAL

Application Areas: Open Pit Metal Mining.

Pod Dimensions (W x H x B): 58x77x110 mm.

Engine Power: 520 kW - 1092 kW.

Operating Weight: 80 - 200 Tones.

Tyre Size: 45 / 65-39 - 45 / 65-45 - 50 / 65-51 - 50 / 80-57.

TYRE PROTECTION CHAIN TYPES AND SIZES

X14 ROYALROCK

Application Areas: Scrapyard, Recycling, Quarry, Construction, Tunnel.

Pod Dimensions (W x H x B): 23x46x78 mm.

Engine Power: 70 kW - 125 kW.

Operating Weight: 10 - 28 tons.

Tyre Size: 17.5 × 25 - 20.5 × 25 - 23.5 × 25.

TYRE PROTECTION CHAIN TYPES AND SIZES

X18 ROYALROCK

Application Areas: Granite/Marble Quarry, Open Pit Metal Mining.
Pod Dimensions (W x H x B): 30x60x99 mm.
Engine Power: 274 kW - 403 kW.
Operating Weight: 56 - 82 tons.
Tyre Size: 26.5 × 25 - 29.5 × 25 - 35 / 65-33.

TYRE PROTECTION CHAIN TYPES AND SIZES

X20 ROYALROCK

Application Areas: Granite Quarry, Open Pit Metal Mining.

Pod Dimensions (W x H x B): 36x70x110 mm.

Engine Power: 403 kW - 607 kW.

Operating Weight: 50 - 100 tons.

Tyre Size: 35 / 65-33 - 40 / 65-39 - 45 / 65-45.

TYRE PROTECTION CHAIN TYPES AND SIZES

X23 ROYALROCK

Application Areas: Open Pit Metal Mining.
Pod Dimensions (W x H x B): 61x85x115 mm.
Engine Power: 720 kW - 1,715 kW.
Operating Weight: 130 - 400 tons.
Tyre Size: 50 / 65-51 - 50 / 80-57 - 53 / 85-57 - 60 / 80-57.

TYRE PROTECTION CHAIN TYPES AND SIZES

X16 SUPERSTONE

Application Areas: Scrapyard, Recycling, Quarry, Marble/Limestone Quarry, Construction, Tunnel.

Pod Dimensions (W x H x B): 24x50x81 mm.

Engine Power: 115 - 274 kW.

Operating Weight: 15 - 35 tons.

Tyre Size: 17.5 × 25 - 20.5 × 25 - 23.5 × 25 - 26.5 × 25 - 29.5 × 25.

TYRE PROTECTION CHAIN TYPES AND SIZES

X18 ULTRA

Application Areas: Marble Quarry, Quarry.

Pod Dimensions (W x H x B): 23x54x92 mm.

Engine Power: 274 kW - 403 kW.

Operating Weight: 56 - 82 tons.

Tyre Size: 26.5 × 25 - 29.5 × 25 - 35 / 65-33.

TYRE PROTECTION CHAIN TYPES AND SIZES

X18 UNDERGROUND

Application Areas: Underground Mining.

Pod Dimensions (W x H x B): 46x66x93 mm.

Engine Power: 199 kW - 403 kW.

Operating Weight: 25 - 82 tons.

Tyre Size: 18.00 × 25 - 23.5 × 25 - 26.5 × 25 - 29.5 × 25 - 35 / 65-33.

TYRE PROTECTION CHAIN TYPES AND SIZES

X20 UNDERGROUND

Application Areas: Underground Mining, Hot Slag, Open Pit Metal Mining.

Pod Dimensions (W x H x B): 50x71x105 mm.

Engine Power: 199 kW - 607 kW.

Operating Weight: 25 - 82 tons.

Tyre Size: 18.00 × 25 - 23.5 × 25 - 26.5 × 25 - 29.5 × 25 - 35 / 65-33.

MESH PATTERNS

4X4 SQUARE

A square mesh pattern provides the maximum protection for your tyres and is a good choice for high abrasion applications.

MESH PATTERNS

6x6 HEXAGON

If you require better traction and protection of your tyres then hexagon mesh is the best option for specific surfaces.

MESH PATTERNS

10X10 DECAGON

Deca mesh provides excellent traction characteristics. This mesh pattern allows for wide self-cleaning areas and can be used for lower abrasion applications.

FEATURES & BENEFITS

Features

Save wear on the expensive tyres
Maximise equipment availability due to shoerter down times
Better traction characteristics
Significantly extended tyre service life
Maximum tyre protection
Suitable for high and low abrasion applications
Fits A wide range of machines
Diversity in application areas
Can withstand temperatures up to 1000 °C
Environmentally friendly manufacturing
Highest quality raw steel materials
Warranty and quality certificates

Benefits

Improved productivity of the loaders
Shorter down times
Fewer unplanned stops for servicing
Lower fuel consumption
Reduced operational costs
Optimal final product price

APPLICATIONS

What are the main application areas for Tyre Protection Chains?

Quarrying
Mining
Slag Processing
Scrap Handling
Underground Works
Tunnelling Works
Construction
Marble Quarries

SPECIFICATION

Recommended clearance for Tyre Protection Chains

MODELS	A	B
X12 UNIVERSAL	42 mm (1.65”)	62 mm (2.4”)
X14 ROYALROCK	50 mm (2”)	74 mm (2.9”)
X16 SUPERSTONE	56 mm (2.2”)	82 mm (3.2”)
X18 ULTRA	56 mm (2.2”)	82 mm (3.2”)
X18 ROYARLOCK	68 mm (2.6”)	98 mm (3.8”)
X18 UNIVERSAL	72 mm (2.8”)	100 mm (4”)
X20 ROYALROCK	82 mm (3.2”)	104 mm (4.1”)
X22 UNIVERSAL	90 mm (3.5”)	110 mm (4.3”)
X23 ROYALROCK	100 mm (4”)	120 mm (4.7”)
